IT 700-S ULTRASTAB, IT700-S ULTRASTAB

HOT OFFER// Authorized Distributor
  • MacroQuest Part#IT 700-S
  • ManufacturerLEM
  • Standard Lead TimeNA
  • Part StatusActive
    • $1199.00 - $1429.00
    / Pieces
    |
    Pieces(Min. Order)
    1-4 Pieces $1429.00
    5-9 Pieces $1286.00
    >=10 Pieces $1199.00
    Quantity:
    In Stock
    $1199.00
    (0 In Stock)
    Available
    $1199.00
    LT: 8-12 weeks
    (729 In Stock)
    $0.00
    Selected List
    0
    No Selected Products
    Payment:
    PayPal
    T/T
    Bank Transfer
    Digital Commerce Bank
    SEPA Payment
    US Payment Account
    Deutsche Bank AG
    Deutsche Bank AG, Tokyo Account
    Credit Card/Debit Card
    Login to Order Request Quote
    Description FAQ Review
    Description

    LEM IT 700-S ULTRASTAB IT Series Closed Loop Fluxgate Current Transducer


    LEM IT 700-S Product Overview

    The IT 700-S is a closed-loop Fluxgate current transducer from LEM's ULTRASTAB IT Series, designed for the ultra-high precision measurement of DC, AC, and pulsed currents with galvanic isolation between the primary and secondary circuits . This panel-mount transducer delivers exceptional accuracy for demanding laboratory, calibration, and medical applications.

    Rated for 700 A nominal with a measuring range of ±700 A, it outputs a secondary current of 400 mA at nominal with an outstanding 0.00535% accuracy . Linearity error is 3 ppm, and initial offset is 50 ppm with an extremely low offset drift of 0.5 ppm/K . Response time is <250 µs and frequency bandwidth is 100 kHz (-3 dB) . Supply voltage is ±15 V (±5%) . Mass is 0.8 kg and operating temperature ranges from +10°C to +50°C . Insulation test voltage is 4.6 kV RMS at 50 Hz for 1 minute, with 9 mm creepage and clearance . The 30 mm diameter aperture accommodates round primary conductors . The output interface is via a 9-pin D-Sub male connector .



    LEM IT 700-S Key Specifications

    Parameter

    Value

    Rated current (IPN)

    700 A

    Measuring range (IPM)

    ±700 A

    Secondary nominal current (ISN)

    400 mA

    Conversion ratio (KN)

    1:1750

    Supply voltage (VC)

    ±15 V (±5%)

    Accuracy (X) @ 25°C

    0.00535 %

    Linearity error (εL)

    3 ppm

    Initial offset

    50 ppm

    Offset drift (TCIOE)

    0.5 ppm/K

    Response time (tr)

    <250 µs

    Bandwidth (BW) (-3 dB)

    100 kHz

    Insulation test voltage (Vd)

    4.6 kV RMS / 50 Hz / 1 min

    Creepage/Clearance (dCp/dCl)

    9 / 9 mm

    Aperture

    30 mm diameter

    Operating temp (TA)

    +10°C to +50°C

    Mass (m)

    0.8 kg

    Mounting

    Panel

    Secondary connection

    9-pin D-Sub male

    Technology

    Closed-loop Fluxgate IT type

    Primary signal

    AC + DC

    Standards

    EN 50178, EN 61010-1



    LEM IT 700-S Key Advantages

    The IT 700-S employs closed-loop Fluxgate technology with an electrostatic shield between primary and secondary circuits, delivering 0.00535% accuracy, 3 ppm linearity, and 50 ppm offset while providing galvanic isolation . The Fluxgate principle offers extremely low offset drift of 0.5 ppm/K, ensuring measurement stability over the operating temperature range . The 100 kHz bandwidth and <250 µs response time capture dynamic current signals with high fidelity.

    A key feature is the optically insulated status output and LED indicator confirming normal operation . The transducer can withstand peak currents of 3.5 kA for 100 ms pulses and features an autoreset system after overload conditions . The design offers very low output noise (1 ppm RMS in 0-10 Hz band), high immunity to external interference, no insertion losses, and low noise feedback to the primary conductor .



    LEM IT 700-S Typical Applications

    Feedback element in high-performance gradient amplifiers for MRI
    Feedback element in high-precision, high-stability power supplies
    Calibration units and test benches in laboratories
    Energy measurement and power analyzers
    Medical equipment (X-ray imaging)
    Precision inverter and converter systems
    High-accuracy industrial metrology
    Calibration of current sources



    Why Choose the LEM IT 700-S?

    The IT 700-S combines a 700 A rated current with 0.00535% accuracy in a compact panel-mount package with a 30 mm aperture. Manufactured by LEM, it delivers stable, accurate, and safe current measurement for ultra-high precision applications. The closed-loop Fluxgate design provides exceptional accuracy, extremely low temperature drift, and excellent linearity, while the D-Sub output and status indicator offer flexible system integration. Compliance with EN 50178 and EN 61010-1 industrial standards ensures reliable operation. This transducer is the ideal choice for MRI systems, calibration equipment, precision power supplies, and demanding laboratory applications where absolute accuracy and long-term stability are critical.



    FAQ
    Q
    What is the advantage of MacroQuest?
    A
    Our advantage is that we not only low prices, but we more suited to you.
    Our Keywords is
    New and original parts
    Fast Delivery
    Instock & available
    Short Leadtime
    30-Days returns
    ISO9001 Certification
    1 Year Warranty

    Q: I want to work with MacroQuest because of high quality. But I found your price too high and out of line with the prevailing market level, how should I do?
    A: MacroQuest has been devoted to offer a best price to our customers,if you want to buy it at a cheapper price. Please contact us directly to see if we can negotiate  a cheaper price rate. Or, send us an email with your T/P.
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q: Can MacroQuest offer NET terms?
    A: Yes we can. Please contact with your sales manager for more information.

    Q: How to Request a Quote?
    -A:You have three ways to request a quote:
    1.Choose an item using a search box or browsing through product categories.Click on "Request Quote" button on the Product page.
    2.Click here for feedback on our web.
    3.If you have a BOM list or want to email us directly, please contact:
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q：Are all the parts new and original?
    -A:Yes, all parts are new and original checked by our quality control department.

    Q：How long is your warranty?
    -A:We offer a 1 year warranty for form fit and function for MacroQuest stock.


    Q:  Can I use Credit Card/Debit Card payment for my orders on your website?
    -A:Yes, you can. you can pay on our company via Credit Card/Debit Card（Mastercard, Discover, Visa, American EXpress, Diners).

    Please select the first payment method-Paypal, then you will see Credit Card/Debit Card payment button in the lower right corner.



    My Account

    If you visit our website for the first time or do not have your login and password yet, please complete the new Customer Registration Form and register in our Customers’ database.
    If you have an account, enter your login and password and confirm these with the “Log in” button.
    If necessary, complete the contact person identification form.

    Log In / Registration
    Update Profile Information
    Change Password
    Update Addresses
    Update Payment Cards
    Update Order Preferences
    Update Product Notifications

    Product Information

    Choose an item using a search box or browsing through product categories. While searching, you can use your own previously entered product symbols/references.

    Searching for Products
    Pricing & Availability
    Packaging Options
    RoHS / Legislation
    Technical Support

    Placing Orders

    How to place an order if you have an account at MacroQuest?

    Checkout
    Invoicing & Payment
    Delivery Information
    Favourite
    Parts List (BOM) Upload
    Trade Account
    Quotes
    Quick Buy
    Saved Shopping Baskets
    Scheduled Orders
    Vouchers

    Viewing and Changing Orders

    The on-line orders system within the MacroQuest’s service works at real time, thanks to which it is immediately (at the moment of placing the order) possible to make a reservation for the selected product in the warehouse what it will be automatically noted in the on-line service.
    If you order a product, it will be reserved for you.
    You can make changes in quantity in the cart, by adding and removing items from the not closed order, before you direct them to realization with the “finish the order” button.

    Order Status & Tracking
    Request an Invoice
    Cancel an Order

    Returning a Product

    RMA# is required for all returns. They are issued for returns that are within 30 days of the initial purchase.

    Return Policy
    How to Return a Product


    Less
    Review
    Freda
    Feb 25, 2026
    It's comfortable doing business with you.
    Queenie
    Oct 30, 2025
    Great company to work with. Simon and Alice AA+++
    Nunez
    Apr 19, 2025
    Good quality, fast delivery,
    Wayne
    Dec 25, 2023
    Receive in the morning,genuine
    Roderick
    Aug 03, 2022
    Fast ,fair price,good parts,
     12
    Review
    ver_code
    1/3
    X
    Send your message to us
    elsa Alice
    Simon Alice elsa
    pop_close
    pop_main
    Stay In The Know
    Enter your email to hear from us about Product list, Latest Products and Customer application examples!
