LA 125-P/SP1 , LA125-P/SP1

HOT OFFER// Authorized Distributor
  • MacroQuest Part#LA 125-P/SP1
  • ManufacturerLEM
  • Standard Lead TimeNA
  • Part StatusActive
    • $29.28 - $48.57
    / Pieces
    |
    Pieces(Min. Order)
    1-9 Pieces $48.57
    10-99 Pieces $41.57
    100-499 Pieces $36.28
    500-999 Pieces $31.11
    >=1000 Pieces $29.28
    Quantity:
    In Stock
    $29.28
    (0 In Stock)
    Available
    $29.28
    LT: 4-6 weeks
    (4834 In Stock)
    $0.00
    Selected List
    0
    No Selected Products
    Payment:
    PayPal
    T/T
    Bank Transfer
    Digital Commerce Bank
    SEPA Payment
    US Payment Account
    Deutsche Bank AG
    Deutsche Bank AG, Tokyo Account
    Credit Card/Debit Card
    Login to Order Request Quote
    Description FAQ Review
    Description

    LEM LA 125-P/SP1 LA Series Closed Loop Current Transducer



    LEM LA 125-P/SP1 Product Overview

    The LA 125-P/SP1 is a closed-loop Hall effect current transducer from LEM's LA Series, designed for the electronic measurement of DC, AC, and pulsed currents with galvanic isolation between the primary circuit and the secondary circuit . This PCB-mount transducer features an 11 x 13 mm aperture for primary conductor crossing and is the SP1 variant with a special 1:2000 turns ratio, providing a 62.5 mA output at nominal current .

    Rated for 125 A nominal with a measuring range of 0 to ±200 A, it outputs a secondary current of 62.5 mA with ±0.6% accuracy and <0.15% linearity . Response time is <1 µs and frequency bandwidth is DC to 100 kHz . Supply voltage range is ±12 V to ±15 V with a current consumption of 16 mA plus IS . Mass is 40 g and operating temperature ranges from -25°C to +85°C . Insulation test voltage meets EN 50178:1997 standards . The insulating plastic case is recognized according to UL 94-V0 . Measuring resistance (RM) varies with supply voltage: with ±12 V, RM is 0-90 Ω at ±125 A and 0-30 Ω at ±200 A; with ±15 V, RM is 0-135 Ω at ±125 A and 0-55 Ω at ±200 A .



    LEM LA 125-P/SP1 Key Specifications

    Parameter

    Value

    Rated current (IPN)

    125 A

    Measuring range (IPM)

    0 to ±200 A

    Secondary nominal current (ISN)

    62.5 mA

    Turns ratio (KN)

    1:2000

    Supply voltage (VC)

    ±12 V to ±15 V (±5%)

    Accuracy (X) @ 25°C

    ±0.60 %

    Linearity error (εL)

    <0.15 %

    Reaction time (10% IPN)

    <500 ns

    Response time (90% IPN)

    <1 µs

    Bandwidth (BW) (-1 dB)

    DC to 100 kHz

    Offset current (IO) @ 25°C

    ±0.20 mA (typ)

    Operating temp (TA)

    -25°C to +85°C

    Storage temp (TS)

    -40°C to +90°C

    Mass (m)

    40 g

    Mounting

    PCB (through-hole)

    Technology

    Closed-loop Hall effect

    Standards

    EN 50178:1997



    LEM LA 125-P/SP1 Key Advantages

    The LA 125-P/SP1 employs closed-loop Hall effect technology, delivering ±0.6% accuracy and <0.15% linearity while providing galvanic isolation between primary and secondary circuits . The ±200 A measuring range accommodates significant overload conditions up to 3× IPN, while the <1 µs response time and 100 kHz bandwidth capture dynamic current signals with high fidelity . The design offers very good linearity, low temperature drift, optimized response time, no insertion losses, and high immunity to external interference . The SP1 variant with 1:2000 conversion ratio provides a 62.5 mA output for compatibility with specific measurement systems .



    LEM LA 125-P/SP1 Typical Applications

    AC variable speed drives and servo motor drives
    Static converters for DC motor drives
    Battery supplied applications
    Uninterruptible Power Supplies (UPS)
    Switched Mode Power Supplies (SMPS)
    Power supplies for welding applications
    Renewable energy systems and solar inverters
    Industrial power conversion equipment



    Why Choose the LEM LA 125-P/SP1?

    The LA 125-P/SP1 combines a 125 A rated current and ±200 A measuring range with 62.5 mA closed-loop current output in a compact PCB-mount package with an 11 x 13 mm aperture. Manufactured by LEM, it delivers stable, accurate, and safe current measurement for industrial power and control applications. The 1:2000 conversion ratio provides design flexibility for systems requiring specific output scaling . The wide -25°C to +85°C operating temperature range and 5-year guarantee ensure reliable performance in demanding environments . This transducer is an ideal choice for motor drives, power supplies, and renewable energy applications where precision and galvanic isolation are essential.



    FAQ
    Q
    What is the advantage of MacroQuest?
    A
    Our advantage is that we not only low prices, but we more suited to you.
    Our Keywords is
    New and original parts
    Fast Delivery
    Instock & available
    Short Leadtime
    30-Days returns
    ISO9001 Certification
    1 Year Warranty

    Q: I want to work with MacroQuest because of high quality. But I found your price too high and out of line with the prevailing market level, how should I do?
    A: MacroQuest has been devoted to offer a best price to our customers,if you want to buy it at a cheapper price. Please contact us directly to see if we can negotiate  a cheaper price rate. Or, send us an email with your T/P.
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q: Can MacroQuest offer NET terms?
    A: Yes we can. Please contact with your sales manager for more information.

    Q: How to Request a Quote?
    -A:You have three ways to request a quote:
    1.Choose an item using a search box or browsing through product categories.Click on "Request Quote" button on the Product page.
    2.Click here for feedback on our web.
    3.If you have a BOM list or want to email us directly, please contact:
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q：Are all the parts new and original?
    -A:Yes, all parts are new and original checked by our quality control department.

    Q：How long is your warranty?
    -A:We offer a 1 year warranty for form fit and function for MacroQuest stock.


    Q:  Can I use Credit Card/Debit Card payment for my orders on your website?
    -A:Yes, you can. you can pay on our company via Credit Card/Debit Card（Mastercard, Discover, Visa, American EXpress, Diners).

    Please select the first payment method-Paypal, then you will see Credit Card/Debit Card payment button in the lower right corner.



    My Account

    If you visit our website for the first time or do not have your login and password yet, please complete the new Customer Registration Form and register in our Customers’ database.
    If you have an account, enter your login and password and confirm these with the “Log in” button.
    If necessary, complete the contact person identification form.

    Log In / Registration
    Update Profile Information
    Change Password
    Update Addresses
    Update Payment Cards
    Update Order Preferences
    Update Product Notifications

    Product Information

    Choose an item using a search box or browsing through product categories. While searching, you can use your own previously entered product symbols/references.

    Searching for Products
    Pricing & Availability
    Packaging Options
    RoHS / Legislation
    Technical Support

    Placing Orders

    How to place an order if you have an account at MacroQuest?

    Checkout
    Invoicing & Payment
    Delivery Information
    Favourite
    Parts List (BOM) Upload
    Trade Account
    Quotes
    Quick Buy
    Saved Shopping Baskets
    Scheduled Orders
    Vouchers

    Viewing and Changing Orders

    The on-line orders system within the MacroQuest’s service works at real time, thanks to which it is immediately (at the moment of placing the order) possible to make a reservation for the selected product in the warehouse what it will be automatically noted in the on-line service.
    If you order a product, it will be reserved for you.
    You can make changes in quantity in the cart, by adding and removing items from the not closed order, before you direct them to realization with the “finish the order” button.

    Order Status & Tracking
    Request an Invoice
    Cancel an Order

    Returning a Product

    RMA# is required for all returns. They are issued for returns that are within 30 days of the initial purchase.

    Return Policy
    How to Return a Product


    Less
    Review
    Devonte
    Mar 28, 2026
    Credible, reliable and honest and always as good as his word.
    Babsi
    Dec 12, 2025
    Great parts. Good supplier.
    Obidinma
    Aug 26, 2025
    The delivery speed is fast, the quality is good and the price is low.
    Emmanuel
    Mar 19, 2024
    The quality is very good,very satisfied
    Westbrook
    Nov 26, 2022
    Reliable source
     12
    Review
    ver_code
    1/3
    X
    Send your message to us
    elsa Alice
    Simon Alice elsa
