LA 305-S , LA305-S

HOT OFFER// Authorized Distributor
  • MacroQuest Part#LA 305-S
  • ManufacturerLEM
  • Standard Lead TimeNA
  • Part StatusActive
    • $85.72 - $120.22
    / Pieces
    |
    Pieces(Min. Order)
    1-9 Pieces $120.22
    10-99 Pieces $105.57
    100-499 Pieces $91.42
    500-999 Pieces $87.77
    >=1000 Pieces $85.72
    Quantity:
    In Stock
    $85.72
    (0 In Stock)
    Available
    $85.72
    LT: 4-6weeks
    (5130 In Stock)
    $0.00
    Selected List
    0
    No Selected Products
    Payment:
    PayPal
    T/T
    Bank Transfer
    Digital Commerce Bank
    SEPA Payment
    US Payment Account
    Deutsche Bank AG
    Deutsche Bank AG, Tokyo Account
    Credit Card/Debit Card
    Login to Order Request Quote
    Description FAQ Review
    Description

    LEM LA 305-S LA305 Series Closed-Loop Current Transducer


    300A Rated Current x ±500A Measuring Range — High-Accuracy Panel-Mount Sensor for Industrial Power Conversion



    LEM LA 305-S Product Overview

    The LA 305-S is a closed-loop Hall effect current transducer from LEM's LA305 series, designed for the electronic measurement of DC, AC, and pulsed currents with galvanic isolation between the primary and secondary circuits . This panel-mount sensor features a compact design with a 25.5 x 25.5 mm aperture for primary conductor crossing . The device offers excellent accuracy, very good linearity, low temperature drift, optimized response time, wide frequency bandwidth, high immunity to external interference, and current overload capability .

    Rated for 300 A nominal with a ±500 A measuring range, it outputs a secondary current of 100 mA (instantaneous) with 0.8% accuracy and <0.1% linearity . Response time is <1 µs and bandwidth is DC to 100 kHz . Supply voltage is ±15 V (±5%) . Mass is 170 g and operating temperature is -40°C to +85°C . Insulation test voltage is 6 kV with a creepage distance of 17.2 mm and clearance of 11 mm . The insulating plastic case is recognized according to UL 94-V0 .



    LEM LA 305-S Key Specifications

    Parameter

    Value

    Rated current (IPN)

    300 A

    Measuring range (IPM)

    0 … ±500 A

    Output signal (ISN)

    100 mA (instantaneous)

    Turns ratio

    1:3000

    Supply voltage (VC)

    ±15 V (±5%)

    Accuracy (XG)

    ±0.8%

    Linearity (EL)

    <0.1%

    Response time (tr)

    <1 µs

    Bandwidth (BW)

    DC … 100 kHz

    Insulation test voltage (Vd)

    6 kV

    Creepage distance (dCp)

    17.2 mm

    Clearance (dCl)

    11 mm

    Aperture

    25.5 x 25.5 mm

    Operating temp (TA)

    -40°C … +85°C

    Mass (m)

    170 g

    Mounting

    Panel (2 holes ⌀5.5 mm)



    LEM LA 305-S Key Advantages

    The LA 305-S employs closed-loop Hall effect technology, delivering 0.8% accuracy and <0.1% linearity while maintaining excellent performance with low temperature drift, optimized response time, wide frequency bandwidth, no insertion losses, high immunity to external interference, and current overload capability . The ±500 A range provides ample headroom for measuring nominal currents up to 300 A with transient overcurrent capability (3 × IPN), while the <1 µs response time and 100 kHz bandwidth capture fast-changing switching waveforms with high fidelity . The 25.5 x 25.5 mm aperture accommodates various primary conductors, and the panel-mount design with two ⌀5.5 mm holes enables flexible installation . The 6 kV insulation and 17.2 mm creepage distance ensure robust safety isolation for demanding industrial applications .



    Why Choose the LEM LA 305-S?

    The LA 305-S combines a 300 A nominal rating with a ±500 A measuring range and 0.8% accuracy in a panel-mount package designed for demanding industrial power conversion and motor control applications . Manufactured by LEM, it delivers stable, accurate, and safe current measurement for critical systems. The closed-loop Hall effect design offers excellent linearity, low thermal drift, and high immunity to external interference, making it a reliable choice for industrial environments where measurement integrity is paramount . The device conforms to EN 50178 standards, features a Molex 5045 connector for secondary connections, and is backed by LEM's 5-year guarantee .



    FAQ
    Q
    What is the advantage of MacroQuest?
    A
    Our advantage is that we not only low prices, but we more suited to you.
    Our Keywords is
    New and original parts
    Fast Delivery
    Instock & available
    Short Leadtime
    30-Days returns
    ISO9001 Certification
    1 Year Warranty

    Q: I want to work with MacroQuest because of high quality. But I found your price too high and out of line with the prevailing market level, how should I do?
    A: MacroQuest has been devoted to offer a best price to our customers,if you want to buy it at a cheapper price. Please contact us directly to see if we can negotiate  a cheaper price rate. Or, send us an email with your T/P.
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q: Can MacroQuest offer NET terms?
    A: Yes we can. Please contact with your sales manager for more information.

    Q: How to Request a Quote?
    -A:You have three ways to request a quote:
    1.Choose an item using a search box or browsing through product categories.Click on "Request Quote" button on the Product page.
    2.Click here for feedback on our web.
    3.If you have a BOM list or want to email us directly, please contact:
    Simon Hsu
    simon@mymacroquest.com
    Alice Wang
    alice@mymacroquest.com

    Q：Are all the parts new and original?
    -A:Yes, all parts are new and original checked by our quality control department.

    Q：How long is your warranty?
    -A:We offer a 1 year warranty for form fit and function for MacroQuest stock.


    Q:  Can I use Credit Card/Debit Card payment for my orders on your website?
    -A:Yes, you can. you can pay on our company via Credit Card/Debit Card（Mastercard, Discover, Visa, American EXpress, Diners).

    Please select the first payment method-Paypal, then you will see Credit Card/Debit Card payment button in the lower right corner.



    My Account

    If you visit our website for the first time or do not have your login and password yet, please complete the new Customer Registration Form and register in our Customers’ database.
    If you have an account, enter your login and password and confirm these with the “Log in” button.
    If necessary, complete the contact person identification form.

    Log In / Registration
    Update Profile Information
    Change Password
    Update Addresses
    Update Payment Cards
    Update Order Preferences
    Update Product Notifications

    Product Information

    Choose an item using a search box or browsing through product categories. While searching, you can use your own previously entered product symbols/references.

    Searching for Products
    Pricing & Availability
    Packaging Options
    RoHS / Legislation
    Technical Support

    Placing Orders

    How to place an order if you have an account at MacroQuest?

    Checkout
    Invoicing & Payment
    Delivery Information
    Favourite
    Parts List (BOM) Upload
    Trade Account
    Quotes
    Quick Buy
    Saved Shopping Baskets
    Scheduled Orders
    Vouchers

    Viewing and Changing Orders

    The on-line orders system within the MacroQuest’s service works at real time, thanks to which it is immediately (at the moment of placing the order) possible to make a reservation for the selected product in the warehouse what it will be automatically noted in the on-line service.
    If you order a product, it will be reserved for you.
    You can make changes in quantity in the cart, by adding and removing items from the not closed order, before you direct them to realization with the “finish the order” button.

    Order Status & Tracking
    Request an Invoice
    Cancel an Order

    Returning a Product

    RMA# is required for all returns. They are issued for returns that are within 30 days of the initial purchase.

    Return Policy
    How to Return a Product


    Less
    Review
    Orietta
    Apr 12, 2026
    Good reliable company!
    Inez
    Mar 25, 2026
    Shipping was fast. Packing was solid.
    Ursula
    Oct 17, 2025
    It's comfortable doing business with you
    Zona
    Jun 07, 2025
    fast shiping, good quality,
    Uriah
    Jan 14, 2024
    A pleasure to work with Good company.
     12
    Review
    ver_code
    1/3
    X
    Send your message to us
    elsa Alice
    Simon Alice elsa
    pop_close
    pop_main
    Stay In The Know
    Enter your email to hear from us about Product list, Latest Products and Customer application examples!
